Zhuang Diao PLC
|
Item |
Specification |
|
Model |
SDV541-S33 S2 |
|
Number of Outputs |
16-channel, module isolation (*5) |
|
Output Voltage |
24 V DC |
|
Output Voltage Drop |
1 V maximum |
|
External Power Supply Rating |
24 V DC, 3.4 A minimum |
|
External Power Supply |
24 V DC + 20 % / -10 % (*1) |
|
Current Capacity |
3.4 A |
|
Maximum Leak Current at Output Off Status |
1.6 mA |
|
Output Format |
Current source |
|
Maximum Load Current |
0.2 A/output line (3.2 A in total output line) (*2) (*5) |
|
Minimum Load Current |
35 mA |
|
Load Resistance Range |
120 to 685 Ω (*3) |
|
Output Response Time |
30 ms maximum |
|
Withstand Voltage |
2 kV AC (between output signal lines and system), 16-point input lines collectively connected |
|
Current Consumption |
300 mA maximum (5 V DC) |
|
|
150 mA maximum (24 V DC) |
|
Weight |
0.29 kg (For pressure clamp terminal block or MIL cable) |
|
|
0.31 kg (With dedicated signal cable interface adapter) |
|
External Connection |
Pressure clamp terminal, MIL cable, Dedicated signal cable |
2: Do not exceed this value, including the case of inrush/variation of the load current.
3: Resistance value of the load for both ON and OFF state, including the field wiring resistance.
4: When connecting SDV541 and SED4D terminal board using AKB331 dedicated signal cable, the withstand voltage is 500V AC (between output signal lines and system). If MIL connector cables are used, the withstand voltage depends on theircable’s electrical specifications.
5: Number of output channels which a user can use and maximum load current are restricted in case of SDV541-SC.
